Generac LP or Natural Gas Air-Cooled Electric Generators

Provides essential circuit power protection for your home, ensuring the necessities remain powered during an outage.

Engine:

Generac (OHVI) Design - Maximizes engine "breathing" for increased fuel efficiency. Plateau honed cylinder walls and plasma moly rings help engine run cooler, reducing oil consumption. Because heat is the primary cause of engine wear, the OHVI has a significantly longer life than competitive engines.
"Spiny-lok" cast iron cylinder walls - Rigid construction and added durability provide long engine life.
Electronic ignition/spark advance - These features combine to assure smooth, quick starting every time.
Full pressure lubrication system - Superior lubrication to all vital bearings means better performance, less maintenance and significantly longer engine life. Now featuring a 2 year/200 hour oil change interval.
Low oil pressure shutdown system - Superior shutdown protection prevents catastrophic engine damage due to low oil.
High temperature shutdown - Prevents damage due to overheating.

Generator:
- Revolving field - Allows for smaller, light weight unit that operates 25% more efficiently than a revolving armature generator.
- Displaced phase excitation - Maximizes motor starting capability.
- Automatic voltage regulation - Regulates the output voltage to 2% prevents damaging voltage spikes.
- UL 2200 Listed - For your safety
Controls:
- Manual/Auto/Off switch - Selects the operating mode.
- Utility voltage sensing - Constantly monitors utility voltage, setpoints 65% dropout, 75% pick-up, of standard voltage.
- Utility voltage sensing - Constantly monitors utility voltage, setpoints 65% dropout, 75% pick-up, of standard voltage.
- Utility interrupt delay - Prevents nuisance start-ups of the engine, setpoint approximately 10 seconds.
- Utility interrupt delay - Prevents nuisance start-ups of the engine, setpoint approximately 10 seconds.
- Engine warm-up - Ensures engine is ready to assume the load, setpoint approximately 10 seconds.
- Engine cool-down - Allows engine to cool prior to shutdown, setpoint approximately 1 minute.
- Seven day exerciser - Operates engine to prevent oil seal drying and damage between power outages.
- Timed Trickle Battery charger - Maintains battery charge level to insure starting.
- Main Line Circuit Breaker - Protects generator from overload.
Unit:
- Weather protective enclosure - Ensures protection against mother nature. Hinged key locking roof panel for security. Lift-out front for easy access to all routine maintenance items. Electrostatically applied textured epoxy paint for added durability.
- Enclosed critical grade muffler Quiet, critical grade muffler is mounted inside the unit to prevent injuries.

Click Image for Larger View

Model ID	Model Name	Continuous Watts NG - LP	Amperage @ 240V NG - LP	Rated HP	Fuel Consumption NG(ccf) - LP(gph) Full Load	Fuel Consumption NG(ccf) - LP(gph) 1/2 Load	dB	HxWxD	Weight
29066	005518-1	7,000 8,000	29.2 33.3	14.8	139 1.68	77 0.94	62	29x25x48	340
29067	005520-1	9,000 10,000	37.5 41.6	18.0	156 1.93	102 1.25	63	29x25x48	387
29068	005522-1	12,000 14,000	54.2 58.3	32.0	220 2.30	156 1.56	66	29x25x48	439
29069	005523-1	16,000 17,000	66.6 70.8	32.0	261 2.57	183 1.61	66	29x25x48	455
29070	005525-1	18,000 20,000	75.0 83.3	36	294 2.90	206 1.89	66	29x25x48	451

Limited 3 Year Warranty Parts

Specification Sheets
- 8, 10, 14 KW
- 17 KW
- 20 KW
